D008 Dome Type Fiber Optic Splice Closure
Capacity of FOSC: Bunchy:12-240(cores); Ribbon:up to 360(cores）
Cable entry ports: 7 pieces
Diameter of Cable: Φ35mm
Protection level: IP68
Description
Description
- Easy to re-enter Cable entry/exit ports
- Pressure testing valve and earth deriving device
- Intergrated seal, air tight and water proof
- Ideal for cable repair
- RoHS compliant
- Can be used in through, branch or mid span splice locations
- Suitable for aerial, underground duct or direct burial applications
- Material : PC
- IP68
Specifications
|
Type
|
Fiber optic splice closure
|
|
Size
|
455*220mm
|
|
Scope
|
Pole mounting, Pedestal mounting,Strand mounting,Wall mounting
|
|
Material
|
PC
|
|
Color
|
Black
|
|
Application
|
FTTH FTTB FTTX Network
|
|
MOQ
|
1 set
|
Packing
| Inner packing | 1 pc/ctn |
| Inner carton size | 240x210x460mm |
| Outer packing | 10 pc/ctn |
| Outer carton size | 645x490x480mm |
| Weight | 3.2kg/pcs |
