GJPFJV Indoor fiber optic cable 48 core
Fiber Type: Single mode G652D/G657A1
Fiber Count: 48 Core
Applications: Indoor introduction / Fiber to the home (FTTH)
Description
Description
- Low polarization sensitivity fiber
- Good mechanical and environmental characteristics
- Flame retardant characteristics meet the requirements of relevant standards.
- The mechanical characteristics meet the requirements of relevant stands
- Soft, flexible easy to splice and with big capacity data transmission
Specifications
|
No. of cable
|
48
|
||
|
Fiber Model
|
G652D
|
||
|
Tight Buffer
|
Material
|
PVC
|
|
|
Thickness（±0.03）mm
|
0.32
|
||
|
Diameter（±0.06）mm
|
0.9
|
||
|
Strength Member
|
Material
|
Aramid Yarn
|
|
|
Unit cable
|
Material
|
LSZH
|
|
|
Thickness（±0.1）mm
|
0.6
|
||
|
Diameter（±0.2）mm
|
5.2
|
||
|
Outer Sheath
|
Material
|
LSZH
|
|
|
Thickness（±0.1）mm
|
1.2
|
||
|
Color
|
Yellow
|
||
|
Cable Diameter（±0.5）mm
|
15.0
|
||
|
Cable Weight（±10）kg/km
|
207
|
||
|
Attenuation
|
1310nm
|
dB/km
|
≤0.36
|
|
1550nm
|
≤0.22
|
||
|
Allowable Tensile Strength
|
Short Term
|
N
|
1320
|
|
Long Term
|
400
|
||
|
Allowable Crush Resistance
|
Short Term
|
N/100mm
|
1000
|
|
Long Term
|
300
|
||
|
Min. bending radius
|
Without Tension
|
10.0×Cable-φ
|
|
|
Under Maximum Tension
|
20.0×Cable-φ
|
||
|
Temperature range
（℃） |
Installation
|
-20~+60
|
|
|
Transport&Storage
|
-40~+60
|
||
|
Operation
|
-40~+60
|
||
Packing
