GJS-H011 Horizontal Fiber Optic Splice Closure
Capacity of FOSC: (bunchy fiber):48
Cable entry ports: 4 Ports
Diameter of Cable: Max φ16
Protection level: IP68
Description
Description
- Easy to re-enter Cable entry/exit ports
- Pressure testing valve and earth deriving device
- Intergrated seal, air tight and water proof
- Ideal for cable repair
- RoHS compliant
- Can be used in through, branch or mid span splice locations
- Suitable for aerial, underground duct or direct burial applications
- Material : PC
- IP68
Specifications
|
Type
|
Fiber optic splice closure
|
|
Size
|
340mm*150mm*70mm |
|
Scope
|
Pole mounting, Pedestal mounting,Strand mounting,Wall mounting
|
|
Material
|
PC
|
|
Color
|
Black
|
|
Application
|
FTTH FTTB FTTX Network
|
|
MOQ
|
1 set
|
Packing
| Inner packing | 1 pc/ctn |
| Inner carton size | 350*170*85mm |
| Outer packing | 10 pc/ctn |
| Outer carton size | 465*360*360mm |
| Weight | 2.2kg/pcs |
