IP68 FTTA Patch Cord Pigtail Mini SC Waterproof Adapter
Fiber Count: 1Core SC
Material:PC/ABS
Applications:
1.Fiber-to-the-Antenna (FTTA)
2.Automation and industrial cabling
3.Surveillance systems
4.Naval and ship building
5.Broadcast
Categories: Fiber Optic Connection, IP68 FTTA Optical Cable Assembly
Description
Description
- Cost effective solution for in house termination
- Low insertion loss and added loss
- Height of attenuation.
- IP68 water, dust proof and corrosion resistant
- The material in the jumpel cable are all-weather and UV-resistant.
- Mechanical performance: IEC 61754-4 standard.
- RoHS and REACH materials compliant.
Specifications
Standards | GR-3120, GR-3152, IEC61753-1, IEC 61754-4 |
Insertion loss | ≤0.5dB |
Return loss | ≥50dB(UPC),≥60dB(APC) |
Repeatability | ≤ 0.1 |
Interchangeability | ≤ 0.2 |
Durability | ≥ 1000 times |
Dust Cap Max. Pulling Force | 100N |
Water Resistance | IP68 |
Operating temperature | -40℃ to + 85℃ |
Storage Temperature | -40 to 85°C |
