IP68 FTTA Patch Cord Pigtail Optitap MPO SC Waterproof connector

Name: IP68 FTTA Patch Cord Pigtail Optitap MPO SC Waterproof connector
Availability: InStock

Fiber Type: OS2(G675a)/OM1/OM2/OM3/OM4
Fiber Count: 1F-12F
Outer Sheath Material:LSZH,TPU
Applications:
1.Fiber-to-the-Antenna (FTTA)
2.Automation and industrial cabling
3.Surveillance systems
4.Naval and ship building
5.Broadcast

Compare

Add to wishlist

Add to quote

Categories: Fiber Optic Connection, IP68 FTTA Optical Cable Assembly

Description
Specifications

Description

Mini diameter Spiral steel reinforced ensures good crush resistance
Aramid yarn strengthened provide good tensile strength
Outer jacket complies with UL, RoHS
Light, flexible and easy to bend
Low insertion loss and high return loss, stable transmission

Specifications

Physical Characteristics
Connector Type	LC/SC/FC/ST/MTP/ODC
Tensile Resistance	Long Term: 200N; Short Term: 600N
Crush Strength	Long Term: 1000 (N/100mm); Short Term: 3000 (N/100mm)
Minimum Bend Radius	Static: 10xD (mm); Dynamic: 20xD (mm)
Cable Jacket	TPU (Thermoplastic Polyurethane) or LSZH
Jacket Color	Black
Cores	1/2/4/ 6/8/12 cores
Fiber type	OS2(G675a)/OM1/OM2/OM3/OM4

Cable Diameter
1-2 Fbier	3.3mm
4-6 Fbiers	4.8mm
8-12 Fbiers	5.0/7.0mm

Optical Characteristics
Connector Insertion Loss	LC/SC/ST/FC/≤0.3dB ; MTP≤0.35dB ; ODC≤1.0dB
Connector Return Loss	SMF: UPC≥50dB; APC≥60dB; MMF: ≥30dB
Fiber Attenuation at 1310 nm	0.36 dB/km
Fiber Attenuation at 1550 nm	0.22 dB/km
Fiber Attenuation at 850 nm	3.0 dB/km
Fiber Attenuation at 1300 nm	1.0 dB/km
