Outdoor Fiber Optic Cable GYTS 48F
Fiber Type: Singlemode / Multimode / OM1 / OM2 / OM3
Fiber Count: 48F
Application: Duct,/Non self-supporting aerial
Categories: Fiber Optic Cable, Outdoor Fiber Cable
Description
Description
- Good mechanical and temperature performance
- High strength loose tube that is hydrolysis resistant
- Special tube filling compound ensure a critical protection of fiber
- Specially designed compact structure is good at preventing loose tubes from shrinking
- PE sheath protects cable from ultraviolet radiation
- The following measures are taken to ensure the cable watertight
- Steel wire used as the central strength member
- Loose tube filling compound
- 100% cable core filling
- APL moisture barrier
Specifications
No. of cable | 48 | ||
Fiber Model | G.652D | ||
Design(StrengthMember+Tube&Filler) | 1+5 | ||
Central Strength Member | Material | Steel wire | |
Diameter(±0.05)mm | 1.4 | ||
Loose Tube | Material | PBT | |
Diameter(±0.06)mm | 1.9 | ||
Thickness(±0.03)mm | 0.3 | ||
The Max.Core NO./Tube | 12 | ||
Filler Rope | Material | PP | |
Colour | White | ||
Diameter(±0.06)mm | 1.9 | ||
Water Blocking layer(Material) | Flooding Compound | ||
Armoring | Material | Steel Strip | |
Thickness(+0.03)mm | 0.20 | ||
Outer Sheath | Material | MDPE | |
Thickness(±0.2)mm | 1.6 | ||
Cable Diameter(±0.2)mm | 9.4 | ||
Cable Weight(±10)kg | 92 | ||
Min. bending radius | Without Tension | 10.0×Cable-φ | |
Under Maximum Tension | 20.0×Cable-φ | ||
Temperature range(℃) | Installation | -20~+60 | |
Transport&Storage | -40~+70 | ||
Operation | -40~+70 |
