Outdoor Fiber Optic Terminal Box FTTH-106C
Size(W*D*H) : 210*140*40mm
Cable Diameter : Φ7～Φ10
Cable Ports : 1+6
Adapter Type : SC/LC
Applications: wall mounted
Applications: wall mounted
Description
Description
- This series are used in the end termination of residential buildings and villas, to fix and splice with pigtails;
- Can be installed on the wall; may adapt variety of optical connection styles;
- optical fiber can be managed effectively
Specifications
| Type | FTTH -106C |
| size(mm)W*D*H | 210*140*40 |
| cable diameter(mm) | Φ7～Φ10 |
| Cable ports | 1+6 |
| Max capacity of splice | 4(single fiber) |
| Adapter | SC or LC |
| IP | 54 |
Packing
| Quantity per carton（piece） | 30 |
| Outer carton dimension(mm) | 470*235*570 |
| Outer carton volume(M3) | 0.063 |
| Outer carton weight（kg） | 10.5 |
