SWOT-H 0212-24 24 Port FTTH Optic Terminal Box

Capacity: 6 port
Connector type: SC simplex, LC duplex
Applications: FTTx wall mount and pole mount

Compare
Add to wishlist
Add to quote
Categories: ,
Description

Description

  • The box casing is made of industrial plastic PP+ABS material. Outdoor application and good UV resistant.
  • Fiber bend radius control more than 35mm.
  • 180 degree access with 2pcs of buckled lock structure.
Specifications
Part No. SWOT-H 0212-24
Dimension 245×296×97 mm
Entry ports and cable dia. Cmax.3 2x22mm
Output ports   and cable dia. (max.) 4×11mm
Output ports   and cable dia. (max.) 8×10mm
Max. number   of splice trays 6 pcs
Splice   capacity of each tray 12/24FO
Max. numbers   of adaptors 24 SC
Cover open   fixed position 90 & 180   degree
Lock   type Key   lock with dust proof cover (Optional)
Installation   way Wall-mounted   or pole-mounted




Performance

Part No. SWOT-H 0212-24
Housing   material ABS+PC
Temperature range -40 oC   to +70 oC.
Flame   resistant V0
Seal   material of the box EPDM
Seal   material of the ports Rubber
Protection   rating IP54

Mounting kit



  • Wall-mounted kit (standard configuration).
  • Pole-mounted kit (Optional)
